About Synthesis
Synthesis Art in Music represents the continuation of 63 years of experience in the field of high end electronics. From the appearance of the earliest valve amplifiers, they have gained the reputation, on the hi-fi market, as a niche product in the broadest and most positive sense of the term.
The exceptional aesthetics, the constant technological research, and an almost maniacal attention to detail make every single Synthesis amplifier a unique piece. Each piece is entirely made in Italy, in one of the few Italian companies in which everything is carefully handmade within the company, with particular care and attention to the transformers.
Products
ROMA PRODUCT LINE-UP
» Roma 79DC Phone Stage / » Roma 753AC Integrated Amp / » Roma 510AC Integrated / » Roma 510AC Signature / » Roma 96DC+ Integrated / » Roma 96DC Integrated / » Roma 117DC Preamp / » Roma 98DC Mono Amp /» Roma 98DC Special Edition / » Roma 37DC+ Hybrid Integrated / » Roma 14DC+ CD Player / » Roma 69DC DAC / » Remote Control
All Roma Models except Roma 510AC Signature come available in these colours:
** THE ROMA 510AC SIGNATURE HAS THE TITAN ALUMINUM FINISH **
Roma 79DC
Tube Phono Stage MM-MC
Synthesis is set to release a new tube phono stage, the Roma79DC.
The all important component of this of this line stage comprises of two ECC83/12AX7 and one ECC82/12AU7 are run by a multi stage fully regulated power supply.
To back this up the design has an over size shielded power transformer for reduce the interference. An array high grade metalized polypropylene capacitors controlling the audio signal circuits. The MM input stage uses a low noise JFet with a separate regulated power supply with extensive filtering for reducing the interference and noise. Using an ECC82/12AU7 tube on the output stage, gives this unit a very low output impedance without losing signal.
The Roma79DC has easily selectable capacitors (MM) and impedances (MC) for cartridges by a front mounted knob selector which is also shown on the front LCD display.
SPECIFICATIONS
Gain stage (1ch.)
1 x 12AX7/ECC83 (MM)
Ultralow noise JFET (MC)
Output stage (1ch.)
1/2 x 12AU7/2CC82
Frequency response:
20Hz – 20KHz +- 1dB
Gain (MM)
40 dB
Gain (MC)
60 dB
Gain (MC+)
65 dB
S/N Ratio
>80 dB (MM) “A” weighted
>70 dB (MC) “A” weighted
Cartridge load
(selectable by front knob)
MM type: 47 KOhm
47/100/150/200/270/320/370/420 pF
MC type: 100 pF
22/33/50/75/100/150/330/1000 Ohm
Output level
>2V RMS
Output impedance
<500 Ohm
Dimensions (w,d,h)
260x380x95 mm
Weight
5Kg
Line Power
117, 230, 245 Vac±10%, 50/60 Hz
(see rear label)
Fuse
(see rear label)
Consumption
30W max
Roma 753AC
Integrated Tube Amp
There has never been an introductory integrated amplifier with the fit, finish and sound of the ROMA 753AC. At first glance, this stunning amp simply takes your breath away. This high performance amplifiers brings out the best of other components in the system. Created by those obsessed with great sound and for those who love great music. The result is 50 watts of pure pentode output per channel built around a pair of 12AU7 on input/driver tubes and a pair of EL34/6CA7 power tubes in push-pull configuration for a detailed, delicate and dynamic sound.
FEATURES
DC Powered tube heater
All tubes, except EL34, have DC stabilized heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a Hi-Grade lron-Silicon for superb frequency reproduction & width. With this newly designed custom output transformer we are able to achieving a highly delicate & precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply & output transformers are held by an extremely rigid structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
It has a soft button design, perfectly matching the aesthetics for the “ROMA” series. It controls volume, mute and sources selection.
Feet
Four aluminum feet with an insert of strong rubber. These rubber feet have been chosen to minimise vibrations of the amplifier in isolation from its surroundings.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Sockets
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the Roma 753AC have been selected with great care throughout. Only the best available components are considered & all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process & at the end of this, selects the perfect tubes which are then matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
2 X EL34/6CA7
Input stage (1 ch.)
1 X 12AU7/ECC82
Driver stage (1 ch.)
1 X 12AU7/ECC82
Input impedance
50KOhm
Input sensitivity
450mV RMS
Output tap
6 Ohm
Configuration
Push-Pull pentode
Power output
(1 ch., THD < 1%)
50W RMS @ 6Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion (MAX Power)
1% @ 1KHz
S/N ratio
>90dB “A” weighted
Inputs
5 line inputs
Outputs
Pre out (variable level)
Bias setting
Manual adjustment, independent for each power tube
Dimensions (w,d,h)
410x420x210mm
Weight
25Kg
Line power
117, 230, 245 Vac, 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
300W Max (753AC)
Roma 510AC Signature
80W Integrated Stereo Tube
It has taken few years of research and development for Synthesis to bring to market the new ROMA510AC Signature. The Signature version has on board the XLR input and MC/MM phono stage.
We introduced the toroidal transformers in amplifiers, which led to improved performance. To back this up the design has an over size shielded power transformer for reduce the interference. The MM and MC inputs stage use a low noise OPA with a separate regulated power supply with extensive filtering for reducing the interference and noise. Using an OPA as buffer on the output stage, gives this unit a very low output impedance without losing signal.
At first glance, this stunning amp simply takes your breath away! This high performance amplifiers brings out the best of other components in the system. Created by those obsessed with great sound and for those who love great music. The result is 80 watts of pure pentode output per channel built around a double triode 12AX7 on input and a 12BH7 tube as phase splitter and a pair of KT88 power tubes in push-pull configuration for a detailed, delicate and dynamic sound.
FEATURES
DC Powered tube heater
All tubes, except KT88, have DC stabilized heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a Hi-Grade lron-Silicon for superb frequency reproduction & width. With this newly designed custom output transformer we are able to achieving a highly delicate & precise sound reproduction faithful to the original recording.
Power transformer
Over size shielded power transformer for reduce the interference.
Mechanical chassis construction
The power supply & output transformers are held by an extremely rigid structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
It has a soft button design, perfectly matching the aesthetics for the “ROMA” series. It controls volume, mute and sources selection.
Feet
Four aluminum feet with an insert of strong rubber. These rubber feet have been chosen to minimize vibrations of the amplifier in isolation from its surroundings.
Binding posts
Gold plated professional binding posts for a continued oxidization free connection further improve sound refinement.
Sockets
Gold plated ceramic sockets for a continued oxidization free connection further improve sound refinement.
Components
Components for the Roma 510AC Signature have been selected with great care throughout. Only the best available components are considered & all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process & at the end of this, selects the perfect tubes which are then matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
2 X KT88
Input stage (1 ch.)
1 X 12AX7/ECC83
Driver stage (1 ch.)
1 X 12BH7
Input impedance
50K Ohm
Input sensitivity
400mV RMS
Output tap
6 Ohm
Configuration
Push-Pull pentode
Power output
(1 ch., THD < 1%) 80W RMS @ 6Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion (MAX Power)
1% @ 1KHz
S/N ratio
>80 dB (MM) “A” weighted
>70 dB (MC) “A” weighted
Cartridge Load (Selectable from rear panel)
MM type: 47KOhm – 47pF
MC type: 100/150/300/47KOhm
Inputs
4 line inputs (n. 3 unbalanced RCA- n. 1 balanced XLR)
1 phono stage MC/MM
Gain Stage
Low noise OPA (MC-MM)
ACCURACY FREQUENCY RESPONSE (RIAA)
20Hz – 20KHz +- 1dB
GAIN (MM)
40 dB
GAIN (MC)
60 dB
Outputs
Pre out (variable level)
Bias setting
Manual adjustment, independent for each power tube
Dimensions (w,d,h)
410x420x210mm
Weight
25Kg
Line power
117, 230, 245 Vac, 50/60 Hz, (see rear label)
Fuse
See rear label
Power consumption
300W Max
Roma 510AC
80W Integrated Stereo Tube Amplifier
Click to open specifications in new window
Roma 96DC+
25W Pure A Class Integrated Stereo Amplifier with Digital Inputs
Roma 69DC
High Resolution Tube DAC
Click to open specifications in new window
ROMA Dedicated Remote control
Synthesis manufactures a dedicated remote control for the Roma series. Featuring a superb CNC machined aluminum body with wood inserts that recalls the Roma Series design. Sold separately.
Specifications
(For the Integrated amplifier and CD Player ONLY)
Body
Anodized black aluminum
Anodized silver aluminum
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute, input, standby, selection, stand-by
Batteries
2 x CR2032
Dimensions (W,D,H)
170x50x20 mm
Weight
200g
Action
Integrated Tube Amplifiers
Action A40 Virtus
40W Integrated Stereo Tube Amplifier
New model of stereo tube amplifiers with DAC’s on board, guaranteeing exceptional sonic performance from any digitai source. Made with the finest materials & advanced technology, this series is a sophisticated blend of research & experience. Designed without compromise far a rich sound & faithful music reproduction.
The A40Virtus provides a minimum of 40 watts per channel, power output from a pair of KT66’s in Ultra-Linear (UL) – push/pull operation.
The A40Virtus features a newly designed custom output transformer resulting in a rich sound stage but with an authority that belies its 40Wpc.
FEATURES
USB & S/PDIF input
For the first time we include an onboard 24Bit 192KHz Wolfson DAC for a extraordinary listening experience.
DC Powered tube heater
Ali tubes, except KT66, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a Hi-Grade lron-Silicon for superb frequency reproduction & width. With this newly designed custom output transformer unique to the A40Virtus we are able to achieving a highly delicate & precise sound reproduction faithful to the originai recording.
Mechanical chassis construction
The power supply & output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
Featuring a superb CNC machined case it has a soft button design, perfectly matching the aesthetics for the “ACTION” series.
Feet
Four CNC machined aluminium feet with an insert of natural rubber. The depth & form of these rubber feet has been calculated to minimise vibrations of the amplifier in isolation from its surroundings.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Sockets
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the A40Virtus have been selected with great care throughout. Only the best available components are considered & all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process & at the end of this, selects the perfect tubes which are then matched for a perfect balance.
SPECIFICATIONS:
Power stage (1 ch.): 2 X KT66
Input stage (1 ch.): 1 X 12AX7/ECC83
Driver stage (1 ch.): 1 X 12BH7
Input impedance:
50KOhm
75 Ohm (S/PDIF)
Input sensitivity
150mV RMS
Output tap
6 Ohm
Configuration
Push-Pull Ultra linear 43% tap
Power output (1 ch., THD < 1%)
40W RMS @ 6Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
4 line inputs
1 S/PDIF input
1 USB input
D/A Converter
2 X WM8740, dual mono configuration,192KHz oversampling
S/PDIF format
PCM 32-192KHz, 16-24 bit
USB interface
PCM 16bit 48KHz, standard audio device, no driver required
Outputs
Pre out (variable level)
Bias setting
Manual adjustment, independent for each power tube
Dimensions (w,d,h)
410x520x235mm
Weight
35Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
350W Max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute, input selection, st-by
Batteries
2 x CR2032
Weight
200g
Action A50Taurus
50W Integrated Stereo Tube Amplifier
Three models of stereo tube amplifiers with DAC’s on board, guaranteeing exceptional sonic performance from any digital source. Made with the finest materials & advanced technology, this series is a sophisticated blend of research & experience. Designed without compromise for a rich sound & faithful music reproduction.
The A50Taurus provides a minimum of 100 watts (50W per channel), power output from 4, KT88/6550’s in Ultra-Linear (UL) – push/pull operation.
The A50Taurus like it’s bigger brother also features a newly designed custom output transformer resulting in a rich sound stage but with an authority that belies its 50W.
FEATURES
USB & S/PDIF input
For the first time we include an onboard 24Bit 192KHz Wolfson DAC for a extraordinary listening experience.
DC Powered tube heater
All tubes, except KT88/6550, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a Hi-Grade Iron-Silicon for superb frequency reproduction & width. With this newly designed custom output transformer unique to the A50Taurus we are able to achieving a highly delicate & precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply & output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
Featuring a superb CNC machined case it has a soft button design, perfectly matching the aesthetics for the “ACTION” series.
Feet
Four CNC machined aluminium feet with an insert of natural rubber. The depth & form of these rubber feet has been calculated to minimise vibrations of the amplifier in isolation from its surroundings.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Sockets
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the A50Taurus have been selected with great care throughout. Only the best available components are considered & all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process & at the end of this, selects the perfect tubes which are then matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.): 2 X KT88
Input stage (1 ch.): 1 X 12AX7/ECC83
Driver stage (1 ch.): 1 X 12BH7
Input impedance
50KOhm
75 Ohm (S/PDIF)
Input sensitivity
150mV RMS
Output tap
6 Ohm
Configuration
Push-Pull Ultra linear 43% tap
Power output (1 ch. THD < 1%)
50W RMS @ 6Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
4 line inputs
1 S/PDIF input
1 USB input
D/A Converter
2 X WM8740, dual mono configuration, 192KHz oversampling
S/PDIF format
PCM 32-192KHz, 16-24 bit
USB interface
PCM 16bit 48KHz, standard audio device, no driver required
Outputs
Pre out (variable level)
Bias setting
Manual adjustment, independent for each power tube
Dimensions (w,d,h)
410x520x235mm
Weight
35Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
350W Max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute, input selection, st-by
Batteries
2 x CR2032
Weight
200g
Integrated Stereo Amplifiers
Metropolis NYC100i
100W Dual Mono Integrated Amplifier
SYNTHESIS is proud to introduce a stereo tube amplifier incorporating the exceptional the sonic performance. The NYC 100i provides a minimum of 200 watts (100W per channel), power output from 8, KT66’s in Ultra-Linear (UL) – push/pull operation. The NYC 100i features a newly designed custom output transformer designed to achieve highly delicate and precise sound with extraordinary musicality from tubes, but with the authority of the best transistor amplifier.
Available in these Finishes
WOOD
DARK
BLACK
FEATURES
Aluminum Knobs
Two 45mm CNC machined control knobs with integral soft light and laser etched indication segments.
DC Powered tube heater
All tubes, except KT66, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a double C-core Hi-Grade Iron-Silicon for superb frequency reproduction and bandwidth. With this newly designed custom output transformer unique to the NYC100i we are able to achieving highly delicate and precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply and output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
A superb wooden handmade case with soft button design, perfectly matching the aesthetics for the “Metropolis” series.
Feet
Four CNC machined aluminum feet with an insert of natural rubber. The depth and form of these rubber feet is calculated to minimize the vibration of the amplifier in isolation from its surroundings.
Fan
A 120mm fan provides a speed between 500 to 700 rpm which is controlled via micro. This ULN (Ultra-Low-Noise) unit is tailor made for the serious enthusiast who demands super-slow running speeds and the utmost silence of operation.
Bias control
The factory set fine bias control is microprocessor controlled to maintain the optimum settings. If required this can be adjusted without the use of an external voltmeter by use of an internally fitted display device.
Dual Mono Circuitry
A completely dual mono design minimises the crosstalk across channels. Power transformers use hi-grade iron silicon M0 and separate supplies with hi-grade selected capacitors to produce extremely low ripple levels. Independent to the mains transformer, each channel has a separate power supply guaranteeing a large reservoir of energy to meet the demands of the amplifier circuit and to maintain excellent interference immunity between channels.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Socket
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the NYC 100i have been selected with great care throughout. Only the best available components are considered and all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process and at the end of this, selects the perfect tubes which are matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
4 X KT66
Input stage (1 ch.)
1 X 12AX7/ECC83
Driver stage (1 ch)
1 X 12BH7
Input impedance
50 KOhm
Input sensitivity
400mV RMS
Output tap
4/8 Ohm bi-wiring connection
Configuration
Push-Pull Ultra linear 20% tap
Power Output (1 ch., THD < 1%)
100W RMS @ 4/8 Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
4 line unbalanced (RCA)
1 line balanced (XLR)
Outputs
Pre out (variable level)
Bias setting
Manual adjustment by LED indicator
Independent for each power tube
Dimensions (w,d,h)
470x620x260mm
Weight
60Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
500W Max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute
Batteries
2 x CR2032
Weight
200g
Metropolis NYC175i
180W Dual Mono Integrated Amplifier
SYNTHESIS is proud to introduce a stereo tube amplifier incorporating the exceptional the sonic performance. The NYC 175i provides a minimum of 360 watts (180W per channel), power output from 8, KT88/6550’s in Ultra-Linear (UL) – push/pull operation.
The NYC 175i features a newly designed custom output transformer designed to achieve highly delicate and precise sound with extraordinary musicality from tubes, but with the authority of the best transistor amplifier.
Available in these Finishes
WOOD
DARK
BLACK
FEATURES
Aluminum Knobs
Two 45mm CNC machined control knobs with integral soft light and laser etched indication segments.
DC Powered tube heater
All tubes, except KT88/6550, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a double C-core Hi-Grade Iron-Silicon for superb frequency reproduction and bandwidth. With this newly designed custom output transformer unique to the NYC175i we are able to achieving highly delicate and precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply and output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
A superb wooden handmade case with soft button design, perfectly matching the aesthetics for the “Metropolis” series.
Feet
Four CNC machined aluminium feet with an insert of natural rubber. The depth and form of these rubber feet is calculated to minimize the vibration of the amplifier in isolation from its surroundings.
Fan
A 120mm fan provides a speed between 500 to 700 rpm which is controlled via the supplied adapter. This ULN (Ultra-Low-Noise) unit is tailor made for the serious enthusiast who demands super-slow running speeds and the utmost silence of operation.
Bias control
The factory set fine bias control is microprocessor controlled to maintain the optimum settings. If required this can be adjusted without the use of an external voltmeter by use of an internally fitted display device.
Dual mono Circuitry
A completely dual mono design minimises the crosstalk across channels. Power transformers use hi-grade iron silicon M0 and separate supplies with hi-grade selected capacitors to produce extremely low ripple levels. Independent to the mains transformer, each channel has a separate power supply guaranteeing a large reservoir of energy to meet the demands of the amplifier circuit and to maintain excellent interference immunity between channels.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Socket
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the NYC 175i have been selected with great care throughout. Only the best available components are considered and all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process and at the end of this, selects the perfect tubes which are matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
4 X KT88
Input stage (1 ch.)
1 X 12AX7/ECC83
Driver stage (1 ch)
1 X 12BH7
Input impedance
50 KOhm
Input sensitivity
400mV RMS
Output tap
4/8 Ohm bi-wiring connection
Configuration
Push-Pull Ultra linear 20% tap
Power Output (1 ch., THD < 1%)
180W RMS @ 4/8 Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
4 line unbalanced (RCA)
1 line balanced (XLR)
Outputs
Pre out (variable level)
Bias setting
Manual adjustment by LED indicator
Independent for each power tube
Dimensions (w,d,h)
470x620x260mm
Weight
60Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
750W Max
Remote control
Body
Anodized black aluminum
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute
Batteries
2 x CR2032
Weight
200g
Metropolis NYC200i
230W Dual Mono Integrated Amplifier
SYNTHESIS is proud to introduce a stereo tube amplifier incorporating the exceptional the sonic performance.
The NYC 200i provides a minimum of 460 watts (230W per channel), power output from 8, KT120’s in Ultra-Linear (UL) – push/pull operation.
The NYC 200i features a newly designed custom output transformer designed to achieve highly delicate and precise sound with extraordinary musicality from tubes, but with the authority of the best transistor amplifier.
Available in these Finishes
WOOD
DARK
BLACK
FEATURES
Aluminum Knobs
Two 45mm CNC machined control knobs with integral soft light and laser etched indication segments.
DC Powered tube heater
All tubes, except KT120, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a double C-core Hi-Grade Iron-Silicon for superb frequency reproduction and bandwidth. With this newly designed custom output transformer unique to the NYC200i we are able to achieving highly delicate and precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply and output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Remote control
A superb wooden handmade case with soft button design, perfectly matching the aesthetics for the “Metropolis” series.
Feet
Four CNC machined aluminium feet with an insert of natural rubber. The depth and form of these rubber feet is calculated to minimize the vibration of the amplifier in isolation from its surroundings.
Fan
A 120mm fan provides a speed between 500 to 700 rpm which is controlled via the supplied adapter. This ULN (Ultra-Low-Noise) unit is tailor made for the serious enthusiast who demands super-slow running speeds and the utmost silence of operation.
Bias control
The factory set fine bias control is microprocessor controlled to maintain the optimum settings. If required this can be adjusted without the use of an external voltmeter by use of an internally fitted display device.
Dual mono Circuitry
A completely dual mono design minimises the crosstalk across channels. Power transformers use hi-grade iron silicon M0 and separate supplies with hi-grade selected capacitors to produce extremely low ripple levels. Independent to the mains transformer, each channel has a separate power supply guaranteeing a large reservoir of energy to meet the demands of the amplifier circuit and to maintain excellent interference immunity between channels.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Socket
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the NYC 200i have been selected with great care throughout. Only the best available components are considered and all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process and at the end of this, selects the perfect tubes which are matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
4 X KT120
Input stage (1 ch.)
1 X 12AX7/ECC83
Driver stage (1 ch.)
1 X 12BH7
Input impedance
50 KOhm
Input sensitivity
400mV RMS
Output tap
4/8 Ohm bi-wiring connection
Configuration
Push-Pull Ultra linear 20% tap
Power Output (1 ch., THD < 1%)
230W RMS @ 4/8 Ohm
Frequency response
from 20Hz to 20KHz ± 0.5dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
4 line unbalanced (RCA)
1 line balanced (XLR)
Outputs
Pre out (variable level)
Bias setting
Manual adjustment by LED indicator
Independent for each power tube
Dimensions (w,d,h)
470x620x260mm
Weight
60Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
800W Max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute
Batteries
2 x CR2032
Weight
200g
Tube Power Amplifiers
Metropolis NYC500
500W Tube Mono Power Amplifier
SYNTHESIS is proud to introduce a Mono Power Tube Amplifier incorporating the exceptional the sonic performance. The NYC500 provides a minimum of 500 watts RMS power output from 8 KT120’s in Ultra-Linear (UL) – push/pull operation in 4 ohm and 8 ohm. The NYC500 features a newly designed custom output transformer designed to achieve highly delicate and precise sound with extraordinary musicality from tubes, but with the authority of the best transistor amplifier.
Available in these Finishes
WOOD
DARK
BLACK
FEATURES
DC Powered tube heater
All tubes, except KT120, have DC stabilized heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a double C-core Hi-Grade Iron-Silicon for superb frequency reproduction and bandwidth. With this newly designed custom output transformer unique to the NYC500 we are able to achieving highly delicate and precise sound reproduction faithful to the original recording.
Mechanical chassis construction
The power supply and output transformers are held by an extremely rigid “H” structure that keeps the unit free from unwanted vibrations which further helps reduce unwanted noise to the tubes.
Feet
Four CNC machined aluminum feet with an insert of natural rubber. The depth and form of these rubber feet minimize the vibration of the amplifier in isolation from its surroundings.
Fan
A 120mm fan provides a speed between 500 to 700 rpm which is controlled via micro. This ULN (Ultra-Low-Noise) unit is tailor made for the serious enthusiast who demands super-slow running speeds and the utmost silence of operation.
Bias control
The factory set fine bias control is microprocessor controlled to maintain the optimum settings. If required this can be adjusted without the use of an external voltmeter by use of an internally fitted display device.
Dual mono Circuitry
A completely dual mono design minimizes the crosstalk across channels. Power transformers use hi-grade iron silicon M0 and separate supplies with hi-grade selected capacitors to produce extremely low ripple levels. Independent to the mains transformer, each channel has a separate power supply guaranteeing a large reservoir of energy to meet the demands of the amplifier circuit and to maintain excellent interference immunity between channels.
Binding posts
Two pairs each output (predispose for bi-wiring connection) of gold plated professional binding posts for a continued oxidization free connection further improve sound refinement.
Socket
Gold plated ceramic sockets for a continued oxidization free connection further improve sound refinement.
Components
Components for the NYC500 have been selected with great care throughout. Only the best available components are considered and all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process and at the end of this, selects the perfect tubes which are matched for a perfect balance.
SPECIFICATIONS
Power stage (1 ch.)
8 X KT120
Input stage (1 ch.)
2 X 12AU7/ECC82
Driver stage (1 ch.)
2 X 12BH7
Input impedance
100KOhm
Input sensitivity
2,4V RMS unbalanced input (RCA)
4,8V RMS balanced input (XLR)
Output tap
4/8 Ohm bi-wiring connection
Configuration
Push-Pull Ultra linear 20% tap
Power Output
500W RMS @ 4/8 Ohm (THD 1%)
550W RMS @ 4/8 Ohm (THD 3%)
Frequency response
20Hz to 20KHz ± 0dB
2Hz to 70KHz – 3dB
Distortion
1% @ 1KHz (Max Power)
S/N ratio
>90dB “A” weighted
Inputs
1 line unbalanced (RCA)
1 line balanced (XLR)
Outputs
Pre out (variable level)
Bias setting
Manual adjustment by LED indicator
Independent for each power tube
Dimensions (w,d,h)
470x620x260mm
Weight
60Kg
Line power
117, 230, 245 Vac 50/60 Hz (see rear label)
Fuse
See rear label
Power consumption
1500W Max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute
Batteries
2 x CR2032
Weight
200g
FCO 300B
Dual mono pure class A Single Ended Amplifier
The amplifier FCO-300B is capable of reproducing music with speed, contrast, body and the life-like presentation of instruments. With this model, using the Single Ended configuration in pure class A, we managed to obtain the musicality we were looking for with dynamics, bass control and power output able to drive a broad range of speakers. Available in Aluminum Silver finish.
The high quality of components used gave to the project a better resolution that reveal to the listener hears a life-like presentation of the musical performance.
FEATURES
Aluminium Knobs
60mm CNC machined control knobs with integral soft light and laser etched indication segments.
DC Powered tube heater
All tubes, have DC stabilised heater circuits to reduce hum noise to a near in-audible minimum.
Output transformer
The Output transformer uses a double C-core Hi-Grade Iron-Silicon for superb frequency reproduction and bandwidth. With this newly designed custom output transformer unique to the FCO-300B we are able to achieving highly delicate and precise sound reproduction faithful to the original recording.
Mechanical construction of the frame.
The power supply, choke and output transformers are resin cast in a metal case which provides the unit free from unwanted vibrations which further helps reduce unwanted noise at the tubes.
Remote control
A superb CNC machined aluminium body with soft button design, perfectly matching the aesthetics for the “FCO” series.
Bias control
The factory set fine bias control is microprocessor controlled to maintain the optimum settings. No adj are required when the power tube is changed.
Dual mono Circuitry
A completely dual mono design minimises the crosstalk across channels. Power transformers use hi-grade iron silicon M0 and separate supplies with hi-grade selected capacitors to produce extremely low ripple levels. Independent to the mains transformer, each channel has a separate power supply guaranteeing a large reservoir of energy to meet the demands of the amplifier circuit and to maintain excellent interference immunity between channels.
Binding posts
Gold plated professional binding posts for a continued oxidisation free connection further improve sound refinement.
Socket
Gold plated ceramic sockets for a continued oxidisation free connection further improve sound refinement.
Components
Components for the FCO-300B have been selected with great care throughout. Only the best available components are considered and all must undergo an exhaustive analysis of their sonic influence prior to final selection.
Selected tubes
All tubes used are selected after 2 stage warm up. A fully computer monitored machine controls the process and at the end of this, selects the perfect tubes which are matched for a perfect balance.
SPECIFICATIONS
Single Channel
Power stage
300B
Input stage
1x 12AU7 – 1x 12AX7
Driver
1x 6CG7
Power supply
1x 5U4G
Power supply filter
CLC configuration
Tube filament
Electronic stabilized
Power transformer
Toroidal transformer Hi-Grade Iron Steel
Output transformer
Double C-Core transformer Hi-Grade Iron Steel
Output tap
4 ohm / 8 ohm
Power stage configuration
Single Ended class A
Bias setting
Automatic Bias controlled by dedicated circuit
Power output (1KHz)
Distortion 1%: 8W@ 4/8 ohm
Distortion 3%: 10W @ 4/8 ohm
Frequency response
10Hz to 50KHz +- 1dB
Input impedance
100Kohm
Input sensitivity (Integrated)
250mV for rated power
Input sensitivity (Power amp)
250mV for rated power
Signal/Noise ratio
>90dB, A weighted
Inputs (line)
4 Balanced line input (XLR)
4 Unbalanced line input (RCA)
(switchable from front panel and remote control)
Integrated/Power amp
Modality switchable from front panel
Remote control
Volume, Mute, Inputs, Stby.
Finish (front panel)
Anodized Aluminum Silver
Finish (body)
Metal painted dark grey
Dimensions (w,d,h)
505x635x320mm
Weight
45 Kg
Line power
100-120V 60Hz
220-245V 50Hz
Power consumption
300W max
Remote control
Body
Anodized black aluminium
Transmission type
Infrared
Protocol
RC5
Functions
Volume, mute
Batteries
2 x CR2032
Weight
200g
PC-15EU Power Cable
Many music lovers choose Synthesis amplifier to be the backbone of their audio system or home stereo. The reason is simple, these Integrated amplifiers produce an incredible natural sound from any music source. The new series of power cords are designed without compromise for a rich sound & faithful music reproduction, perfect matching with Synthesis products.
Improvements in the focus of the sound stage, depth, harmonics and tonal balance. Low frequencies are more cleaner, with a greater definition and presence.
Each product is individually and carefully handcrafted, inspected and tested before being packed and shipped, pay particular attention to quality and details.
All Synthesis cables are delivered in an attractive, sturdy carrying case.
